Grundfos DMS D Series Product Guide

37
DMS 2 to 4 - standard range
DMS, 60 Hz, 120V with US 120V Plug
Pump Head
Material
Control
Variant
Valve Ball
Material
Connections,
Suction/Discharge
[in]
Gasket
Material
Control
Position
Model
Product
Number
Ship
Weight
[lbs]
DMS 2-11 0.66 GPH (2.5 l/h) up to 160 psi (11 bar)
PP
A
Ceramic 1/4 or 3/8**
EPDM
Front DMS2-11 A-PP/E/C-F-21RRB 96469328
5,0
Side DMS2-11 A-PP/E/C-S-21RRB 96469358
FKM
Front DMS2-11 A-PP/V/C-F-21RRB 96469376
Side DMS2-11 A-PP/V/C-S-21RRB 96469377
AR
EPDM
Front DMS2-11 AR-PP/E/C-F-21RRB 96469391
Side DMS2-11 AR-PP/E/C-S-21RRB 96469392
FKM
Front DMS2-11 AR-PP/V/C-F-21RRB 96469394
Side DMS2-11 AR-PP/V/C-S-21RRB 96469399
B
EPDM Front DMS2-11 B-PP/E/C-F-21RRB 96469451
FKM Front DMS2-11 B-PP/V/C-F-21RRB 96469456
D*
EPDM None DMS2-11 D-PP/E/C-X-21RRB 96508016
FKM None DMS2-11 D-PP/V/C-X-21RRB 96508017
PVDF
A
Ceramic 1/4 or 3/8**
FKM
Front DMS2-11 A-PV/V/C-F-21RRB 96469378
Side DMS2-11 A-PV/V/C-S-21RRB 96469390
AR FKM
Front DMS2-11 AR-PV/V/C-F-21RRB 96469403
Side DMS2-11 AR-PV/V/C-S-21RRB 96469408
B FKM Front DMS2-11 B-PV/V/C-F-21RRB 96469467
D* FK M None DMS2-11 D-PV/V/C-X-21RRB 96508019
SS
A
SS 1/4" NPT
FKM
Front DMS2-11 A-SS/V/SS-F-21VVB 96469419
Side DMS2-11 A-SS/V/SS-S-21VVB 96469424
AR FKM
Front DMS2-11 AR-SS/V/SS-F-21VVB 96469411
Side DMS2-11 AR-SS/V/SS-S-21VVB 96469414
B FKM Front DMS2-11 B-SS/V/SS-F-21VVB 96462492
D* FK M None DMS2-11 D-SS/V/SS-X-21VVB 96508090
DMS 4-7 1.05 GPH (4 l/h) up to 101.5 psi (7 bar)
PP
A
Ceramic 1/4 or 3/8**
EPDM
Front DMS4-7 A-PP/E/C-F-21RRB 96469468
5.0
Side DMS4-7 A-PP/E/C-S-21RRB 96469469
FKM
Front DMS4-7 A-PP/V/C-F-21RRB 96469470
Side DMS4-7 A-PP/V/C-S-21RRB 96469471
AR
EPDM
Front DMS4-7 AR-PP/E/C-F-21RRB 96469474
Side DMS4-7 AR-PP/E/C-S-21RRB 96469487
FKM
Front DMS4-7 AR-PP/V/C-F-21RRB 96469489
Side DMS4-7 AR-PP/V/C-S-21RRB 96469490
B
EPDM Front DMS4-7 B-PP/E/C-F-21RRB 96469513
FKM Front DMS4-7 B-PP/V/C-F-21RRB 96469493
D*
EPDM None DMS4-7 D-PP/E/C-X-21RRB 96508091
FKM None DMS4-7 D-PP/V/C-X-21RRB 96508092
PVDF
A
Ceramic 1/4 or 3/8**
FKM
Front DMS4-7 A-PV/V/C-F-21RRB 96469472
Side DMS4-7 A-PV/V/C-S-21RRB 96469473
AR FKM
Front DMS4-7 AR-PV/V/C-F-21RRB 96469492
Side DMS4-7 AR-PV/V/C-S-21RRB 96469508
B FKM Front DMS4-7 B-PV/V/C-F-21RRB 96469514
D* FKM None DMS4-7 D-PV/V/C-X-21RRB 96508093
SS
A
SS
1/4" NP
T
FKM
Front DMS4-7 A-SS/V/SS-F-21VVB 96469511
Side DMS4-7 A-SS/V/SS-S-21VVB 96469512
AR FKM
Front DMS4-7 AR-SS/V/SS-F-21VVB 96469509
Side DMS4-7 AR-SS/V/SS-S-21VVB 96469510
B FKM Front DMS4-7 B-SS/V/SS-F-21VVB 96462515
D* FKM None DMS4-7 D-SS/V/SS-X-21VVB 96508094
WEIGHTS: Shipping weights are approximate.
* See pg 32 for DMS D capacity range.
** 1/4" = 0.17 ID x 0.25 OD; 3/8" = 0.25 ID x 0.375 OD; 1/2" = 0.375 ID x 0.5 OD.
Pump selection
DME and DMS
Dm123.book Page 37 Tuesday, February 8, 2005 8:24 AM
