Grundfos DMS D Series Product Guide

38
Pump selection
DME and DMS
DMS 8 to 12 - standard range
DMS, 60 Hz, 120V with US 120V Plug
Pump Head
Material
Control
Variant
Valve Ball
Material
Connections,
Suction/ Discharge
[in]
Gasket
Material
Control
Position
Model
Material
Number
Ship
Weight
[lbs]
DMS 8-5 1.98 GPH (7.5 l/h) up to 78.3 psi (5.4 bar)
PP
A
Ceramic 1/4 or 3/8**
EPDM
Front DMS8-5 A-PP/E/C-F-21RRB 96469516
5.0
Side DMS8-5 A-PP/E/C-S-21RRB 96469523
FKM
Front DMS8-5 A-PP/V/C-F-21RRB 96469529
Side DMS8-5 A-PP/V/C-S-21RRB 96469534
AR
EPDM
Front DMS8-5 AR-PP/E/C-F-21RRB 96462494
Side DMS8-5 AR-PP/E/C-S-21RRB 96469637
FKM
Front DMS8-5 AR-PP/V/C-F-21RRB 96469638
Side DMS8-5 AR-PP/V/C-S-21RRB 96469651
B
EPDM Front DMS8-5 B-PP/E/C-F-21RRB 96469676
FKM Front DMS8-5 B-PP/V/C-F-21RRB 96469678
D*
EPDM None DMS8-5 D-PP/E/C-X-21RRB 96508095
FKM None DMS8-5 D-PP/V/C-X-21RRB 96508097
PVDF
A
Ceramic 1/4 or 3/8**
FKM
Front DMS8-5 A-PV/V/C-F-21RRB 96469537
Side DMS8-5 A-PV/V/C-S-21RRB 96469636
AR FKM
Front DMS8-5 AR-PV/V/C-F-21RRB 96469656
Side DMS8-5 AR-PV/V/C-S-21RRB 96469659
B FKM Front DMS8-5 B-PV/V/C-F-21RRB 96469682
D* FKM None DMS8-5 D-PV/V/C-X-21RRB 96508098
SS
A
SS 1/4" NPT
FKM
Front DMS8-5 A-SS/V/SS-F-21VVB 96469672
Side DMS8-5 A-SS/V/SS-S-21VVB 96469675
AR FKM
Front DMS8-5 AR-SS/V/SS-F-21VVB 96469663
Side DMS8-5 AR-SS/V/SS-S-21VVB 96469668
B FKM Front DMS8-5 B-SS/V/SS-F-21VVB 96462686
D* FKM None DMS8-5 D-SS/V/SS-X-21VVB 96508099
DMS 12-3 3.17 GPH (12 l/h) up to 49.3 psi (3.4 bar)
PP
A
Ceramic 1/4 or 3/8**
EPDM
Front DMS12-3 A-PP/E/C-F-21RRB 96469700
5.0
Side DMS12-3 A-PP/E/C-S-21RRB 96469703
FKM
Front DMS12-3 A-PP/V/C-F-21RRB 96469707
Side DMS12-3 A-PP/V/C-S-21RRB 96469711
AR
EPDM
Front DMS12-3 AR-PP/E/C-F-21RRB 96469722
Side DMS12-3 AR-PP/E/C-S-21RRB 96469726
FKM
Front DMS12-3 AR-PP/V/C-F-21RRB 96469730
Side DMS12-3 AR-PP/V/C-S-21RRB 96469734
B
EPDM Front DMS12-3 B-PP/E/C-F-21RRB 96469775
FKM Front DMS12-3 B-PP/V/C-F-21RRB 96469777
D*
EPDM None DMS12-3 D-PP/E/C-X-21RRB 96508100
FKM None DMS12-3 D-PP/V/C-X-21RRB 96508101
PVDF
A
Ceramic 1/4 or 3/8**
FKM
Front DMS12-3 A-PV/V/C-F-21RRB 96469714
Side DMS12-3 A-PV/V/C-S-21RRB 96469718
AR FKM
Front DMS12-3 AR-PV/V/C-F-21RRB 96469735
Side DMS12-3 AR-PV/V/C-S-21RRB 96462495
B FKM Front DMS12-3 B-PV/V/C-F-21RRB 96469786
D* FKM None DMS12-3 D-PV/V/C-X-21RRB 96508103
SS
A
SS
1/4" NP
T
FKM
Front DMS12-3 A-SS/V/SS-F-21VVB 96469766
Side DMS12-3 A-SS/V/SS-S-21VVB 96469771
AR FKM
Front DMS12-3 AR-SS/V/SS-F-21VVB 96469763
Side DMS12-3 AR-SS/V/SS-S-21VVB 96469764
B FKM Front DMS12-3 B-SS/V/SS-F-21VVB 96469791
D* FKM None DMS12-3 D-SS/V/SS-X-21VVB 96508104
WEIGHTS: Shipping weights are approximate.
* See pg 32 for DMS D capacity range.
** 1/4" = 0.17 ID x 0.25 OD; 3/8" = 0.25 ID x 0.375 OD; 1/2" = 0.375 ID x 0.5 OD.
