PHP A-1 Instruction Manual / Operation and display
5.7 User level 3
User level 3 can be unlocked in menu “settings” -
“code input” 1424000
This level is intended for the commissioner of the plant
(e.g. plumber,...).
24
USER LEVEL 3 - MENU STRUCTURE:
User level 3
actions
one-time filling/stop filling
start/stop fast degassing
9)
reset amount
2)
cartridge change MWE
11)
resp. cartridge
change MVE
15)
settings
pressure maintenance
working pressure
operating mode pumps
1)
operating mode level
8)
makeup
operating mode
2)
maximum amount
2)
period of amount
6)
level: start makeup
water hardness
11)
water conductivity
15)
degassing
9)
operating mode
timer program
cycle (normal)
cycle (fast)
duration fast degassing
monitoring
min. press: P1min
max. press: P1max
min. level: Lmin
max. level: Lmax
min. temperature: T1min
max. temperature: T1max
min. temperature: T2min
7)
max. temperature: T2max
7)
general
main display
language
time & date
display contrast
bus module/web module
16)
enable receiving
enable device (only if receiving is enabled)
SMS module
12)
device settings
call numbers
PIN code
messaging settings
send warnings
report blackout
autom. clock-update
autom. status SMS
device set-up
see chapter 6 “commissioning” - “step 8”
manual mode
all outputs: auto
14)
pump M1
pump M2
makeup valve Y1
signalling: makeup
signalling: warning
signalling: fault
code input
1. Only in PHP systems
2. Only if EMCF-1 V makeup module is enabled
6. Only in operating mode ‘time-controlled’
7. Only if sensor T2 is enabled
8. Only if level measurement L2 is enabled
9. Only if degassing is enabled (without bypass)
11. Only if softening MWE is enabled
12. Only if SMS module is enabled
14. Only if at least 1 output is switched to manual mode
15. Only if desalination MVE is enabled
16. Only if bus module resp. web module is enabled
