PHP A-1 Instruction Manual / Operation and display
5.5 Display level
By pressing the key “F1” (display) the display level can
be entered.
This level is used to show measured values and the current
operation status.
After accessing the display level, a number in brackets is
shown. This number is the current active user level, which
will also influence the display level’s items.
DISPLAY LEVEL - MENU STRUCTURE:
Display level... (2)
Pressure maintenance
Current system pressure and vessel level L
Show setpoint
operation pump 1
operation pump 2
1)
overflow pipe temperature T1
Level L1/level L2
8)
operating mode pumps
1) 3)
current priority pump
1)
operating mode level
8)
makeup
current vessel level L and operation makeup
show setpoint
previous overall amount
2)
remaining amount/remaining amount and
remaining time
2) 4)
softening MWE6 remaining capacity resp.
MWE12 remaining capacity
2) 11)
desalination MVE2 remaining capacity resp.
MVE4 remaining capacity
2) 14)
operating mode
3)
degassing
9)
current operating stage state
remaining time
fast degassing
10)
remaining time
operating hours
operating mode
3)
timer program
5)
temperature sensor T2
7)
monitoring
13)
min. pressure: P1 min and current state
max. pressure: P1 max and current state
min. level: L min and current state
max. level: L max and current state
min. temperature: T1 min and current state
max. temperature: T1 max and current state
min. temperature: T2 min and current state
max. temperature: T2 max and current state
7)
statistics
pump M1
operating hours from the displayed time
resettable
pump M2
1)
operating hours from the displayed time
resettable
degassing
9)
operating hours from the displayed time
resettable
temp. measurement T1
peak and time it occurred
resettable
temp. measurement T1
minimum and time it occurred
resettable
temp. measurement T2
7)
peak and time it occurred
resettable
temp. measurement T2
7)
minimum and time it occurred
resettable
press. measurement P1
peak and time it occurred
resettable
press. measurement P1
minimum and time it occurred
resettable
makeup
2)
amount from the displayed time
resettable
water treatment
2) 11)
cartridge changed on ...
not resettable, entry happens when changing
the cartridge
press. maintenance
pressure set-up on ...
not resettable, entry happens when setting the
working pressure
level measurement L1
peak and time it occurred
resettable
level measurement L1
minimum and time it occurred
resettable
level measurement L2
8)
peak and time it occurred
resettable
level measurement L2
8)
minimum and time it occurred
resettable
temp. measurement T1 < ...
operating hours from ...,the blocking temperature
was underrun
19
