PHP A-1 Instruction Manual / Technical data
type usage Main & Auxiliary Vessels
Main & Auxiliary Vessels
nominal content
litre
200 300 500 800
nominal pressure vessel (PN)
bar
0,5
max. temperature at plant connection
°C
70
insertion: tip dimension
mm
1600 1700 2300 2300
dimensions diameter
D mm
500 600 600 800
total height
H mm
1510 1570 2150 2110
clear height above vessel
L mm
500
weight kg
66 80 95 210
connections 1 “
Rp 1”
2 “
Rp 1”
3 “
Rp 1/2” Rp 3/8”
4 mm
DN 50
type usage Main & Auxiliary Vessels
Main & Auxiliary Vessels
nominal content
litre 1.000 1.500 2.000 2.500 3.000 4.000 5.000 10.000
nominal pressure vessel (PN)
bar 0,5
max. temperature at plant connection
°C 70
insertion: tip dimension
mm 2300 2500 2600 3400 3500 3800 3900 5600
dimensions diameter
D mm 900 1050 1200 1050 1200 1400 1500 1700
total height
H mm 2100 2220 2265 3200 3275 3500 3550 5310
clear height above vessel
L mm 500 700 1000
weight kg
250 350 500 550 575 675 775 1500
connections 1 “ Rp 1” Rp 5/4” Rp 6/4” DN 50
2 “ Rp 1” Rp 5/4” Rp 6/4” DN 50
3 “ Rp 3/8” Rp 1/2” Rp 3/4”
4 mm
DN 50 DN 75
1. Overflow pipe from device
2. Suction pipe to device
3. Gas side vessel connection (beneath cover)
4. Discharge hopper
Technical data subject to change without notice.
