2.2.2 Type key
Example of type key: TPED 65-120/2S-A-F-A-BQQE-GDB
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Code TP E D 65 -120 /2 S -A -F -A -BQQE -G D B
Pos. Description
1 Pump range
2 Electronically speed-controlled pump, Series 1000, 2000
3 Twin-head pump
4 Nominal diameter of inlet and outlet ports, DN
5 Maximum head [dm]
6 Pole number
7
Code for pump version. The codes may be combined:
[Blank]: TPE Series 1000 with MGE motor and without sensor
S: TPE Series 2000 with factory-fitted differential-pressure sensor
NC: TPE Series 1000 with Siemens motor with integrated CUE
SC: TPE Series 2000 with built-in differential-pressure sensor and Siemens motor with integrated CUE
8
Code for pump version. The codes may be combined:
A: Basic version
A3: PN 25 flange
B: Oversize motor
(+E): With ATEX approval, certificate or test report, the second character of the code for pump version
is an E
I: PN 6 flange
X: Special version
9
Code for pipe connection:
F: DIN flange
O: Union
10
Code for materials:
A: Basic version
I: Stainless steel 1.4308 pump housing and motor stool
Z: Bronze pump housing and motor stool
B: Bronze impeller
S: Stainless steel 1.4408 impeller
O: Ductile cast-iron pump housing with cast-iron impeller
Y: Ductile cast-iron pump housing with bronze impeller
Q: Ductile cast-iron pump housing with stainless steel 1.4408 impeller
11
Code for shaft seal including other plastic and rubber pump parts, except the neck ring. See Codes for
shaft seal.
12 Code for rated motor power [kW]. See Codes for rated motor power.
13
Code for phase and voltage or other information [V]. See Codes for phase and voltage or other
information.
14 Code for speed variant [rpm]. See Codes for speed variant.
7
