2. Product introduction
2.1 Product description
These instructions apply to the pump types TP and
TPD fitted with Grundfos motors or Siemens motors.
If the pump is fitted with another motor make, please
note that the motor data may differ from the data
stated in these instructions.
2.2 Identification
2.2.1 Nameplate
4
6
H m
n min
-1
%
MEI
η
p
(in.)
HzType/Model f
DK-8850 Bjerringbro, Denmark
9987276 1
Ver.
Q
p/t
Imp. Dia.
0.70 60
TP 80-160/2 A-F-A-BQQE-JX2
A98958110P220150001
10/120
3.56
Made in Hungary
11.5
72.6
3360
m
3
/h
bar/°C
MAX
51.3
1
11
5
3
2
9
7
8
12 10
PEI
CL
:0.89
TM070107
Example of TP nameplate
Legend
Pos. Description
1 Type designation
2 Identification code
A Service model
98958110 Product number
P2 Production site code
2015
Production year and week
(YYWW)
0001 Serial number
3 Nominal flow rate
4 Nominal pump head
5 Pressure rating and maximum temperature
6 Hydraulic efficiency at best efficiency point
7 Minimum efficiency index
8 Frequency
9 Actual impeller diameter
10
Drinking water approval
or Pump Energy Index (PEI)
PEI
CL
: constant load
PEI
VL
: variable load
11 Country of origin
12 Rated pump speed
6
