Chapter 4: Control Panels
Factory Default Settings
You can reference the default factory settings to compare them with any changes you may have made.
Table 4-4 TopDry Terminal Default Settings
Parameter
Factory Value
Units
Drying Mode
AutoFlow
Time or Time/Temp Dry Time & Temp
Wet Tank Switch Disabled
Low Level Switch Enabled
Dry Chamber Overflow Switch
Enabled
Start Fans w/High Level Sw
Disabled
# Aeration Fans 1
# Fill Systems
1
Percent Time Until Unload Off 25
Burner Hi-Lo or On/Off Mode Hi-Lo
# of Burners 1
Burner Differential 1 °F
Dry Timer
20 minutes
Unload Timer 38 seconds
Batch Cool Time 0 minutes
Purge Time
30 seconds
Cool Down Timer 20 minutes
Out of Grain Timer 8 minutes
Fan Off Delay
60 seconds
Fan Start Delay
2.5 seconds
Wet Supply Switch Delay
40 seconds
Low Level Switch Delay
5 seconds
High Level Switch Delay
45 seconds
Load 1 Delay
30 seconds
Load 2 Delay
30 seconds
Grain Temp Setpoint
101
°F
Plenum Temp Setpoint
150
°F
Grain Max Temp
140
°F
Plenum Max Temp
200
°F
Grain Temp Sensor 1 Offset
0
°F
Grain Temp Sensor 2 Offset
0
°F
Grain Temp Sensor 3 Offset
0
°F
Grain Temp Sensor 4 Offset
0
°F
Max Grain Sensor Temp Differential
15
°F
48 Pneg–4900 TopDry Terminal™
