Chapter 4: Control Panels
Table 4-2 Description of the main menu’s buttons and displays (cont'd.)
Item Name Description
12 Grain temperature set-
point button
Shortcut that allows you to quickly modify the setpoint temperature of the
grain; displays the current grain temperature setpoint
13 Plenum temperature
setpoint button
Shortcut that allows you to quickly modify the setpoint temperature of the
plenum; displays the current plenum temperature setpoint
14 Fill system 2 Graphic representation of the second fill system; animates flowing grain
when in operation
15 Fill system 1 Graphic representation of the first fill system; animates flowing grain when in
operation
16 Drying chamber over-
flow switch
Graphic representation of the overflow switch in the drying chamber; only
appears when it senses grain and will blink red
17 High level drying cham-
ber switch
Graphic representation of the high level switch in the drying chamber;
flashes red when not sensing grain; solid green when sensing grain
18 Low level drying cham-
ber switch
Graphic representation of the low level switch in the drying chamber; flashes
red when not sensing grain; solid green when sensing grain
19
Storage chamber high
level switch
Graphic representation of the high level switch in the storage chamber; only
appears when it senses grain and will blink red
20 Burners
Graphic representation of a burner; turns red when in operation
21
Aeration fans Graphic representation of a aeration fan; turns blue when in operation
22 Plenum temperature
Displays the current temperature of the plenum
23
Grain temperature Displays the current temperature of the grain in the drying chamber
Configuring the Operational Settings for the TopDry Terminal
By clicking the Setup icon on the main menu, you can configure settings for your system. These settings
can vary depending on the equipment installed on your TopDry.
What You Should Know
38 Pneg–4900 TopDry Terminal™
