Chapter 5: Getting Started
Fans
• Make sure fans rotate freely in the correct direction.
Electrical Components
• Make sure there are no loose or bare wires.
Testing and Leveling the Dump Chutes
Before attaching the sprocket chain to the lift plate cable, you must test that the sprocket travels from the
open limit switch position to the close limit switch position.
Before You Begin
• Make sure you have completed the pre-season inspections.
• E-Stops are pulled out.
• Make sure the sprockets are aligned correctly.
• Power has been supplied to the system.
• Turn all switches on the TopDry Terminal to OFF.
• Turn the Control Power switch to ON.
• Push the Dryer Power Start button.
To test the chute controller:
NOTE: When the cover is removed, the damper switch (B) must be depressed for the system to
operate during testing.
WARNING
Rotating sprockets can cut and crush. Keep away from all moving parts.
1. Make sure that the bolts (E) on the sprocket (C) are in the open position (G).
2. Set the Dump switch on the TopDry Terminal to Manual Close position.
The bolts (E) on the sprocket (C) should rotate to the closed position (H), tripping the limit switch
(D).
3. Set the Dump switch on the TopDry Terminal to Manual Open position.
The bolts (E) on the sprocket (C) should rotate to the open position (G), tripping the limit switch (D).
4. Connect the sprocket chain and the lift cable to the turnbuckle.
To level the dump chutes:
5. Set the Dump switch on the TopDry Terminal to Manual Close position and inspect the dump
chutes.
The dump chutes should be level in the closed position.
6. Inspect the dump chutes, and if they are not level, use the turnbuckle to adjust the chutes until they
are level.
7. Set the Dump switch on the TopDry Terminal to Manual Open position and inspect the dump
chutes.
52 Pneg–4900 TopDry Terminal™
