1. UPS Structure and Introduction
1.1 UPS structure
1.1.1 UPS Configuration
The UPS configurations are provided in Table 1-1.
Table 1-1 UPS Configuration
Item
Components
Quantity
Remark
10-40kVA
Circuit Breakers
5
Standard
Dual Input
---
Standard
Parallel Card,
1
Optional
Dry Contact Card
1
Standard
Cold start
---
Optional
Dust filter
1
Optional
SNMP
1
Optional
1.1.2 UPS Outlook
The UPS outlooks are shown as figure 1-1.
