Gtec NOVA 10kVA - Terminal and Circuit Breaker Specs

www.gtec-power.de 27
2.6.2 Specifications for Power Cables Terminal
Specifications for power cables connector are listed on Table 2-3.
Table 2-3 Requirements for power terminal
Port
Connection
Bolt
Bolt
Aperture
Torque
Moment
Mains input
Cables crimped
OT terminal
M6
7mm
4,9Nm
Bypass Input
Battery Input
Output
PE
2.6.3 Circuit Breaker
The recommended external circuit breakers (CB) for the system are in Table 2-4.
Table 2-4 Recommended CB
Installed
position
10kVA
15kVA
20kVA
30kVA
40kVA
Input CB
32A/3P
40A/3P
63A/3P
80A/3P
100A/3P
Bypass CB
63A/3P
Output CB
Maintenance CB
Battery CB
32A/3P
40A, 250Vdc
63A, 250Vdc
100A, 250Vdc
125A, 250Vdc
Attention
The CB with RCD (Residual Current Device) is not suggested for the system.
