String Nr.4 with 40 batteries 7/9Ah
String Nr.3 with 40 batteries 7/9Ah
String Nr.2 with 40 batteries 7/9Ah
String Nr.1 with 40 batteries 7/9Ah
Attention: installs the first battery string
in position 1, and so on
The interconnections are made with electrical cables and Anderson type connectors.
Use only original battery Kit.
Measure and confirm correct battery voltage before connecting to UPS
