33
plate will require the rollers to be further extended (convex edge plate) or
recessed (concave edge plate). This is necessary to prevent feeding problems
during bevelling. Regularly check to make sure that the plate is running
against the Guide Rollers as it is being bevelled and that there is only a
minimal gap between the edge of the plate and the face of the Guide Roller
Bracket (directly next to the Guide Rollers), especially when changing setups
between straight edged plates and curved edged plates or disks. See page 14
for further details.
MONTHLY INSPECTIONS
NOTE: The following inspections should be performed with greater frequency if conditions
and usage requires.
Inspect the security of all fasteners.
Inspect the condition of the Slide Base; Guide Roller Bracket; and Chip Deflector, and replace them
if damaged or gouged from wear, or if the cutting chips have worn a pocket that affects smooth chip
flow.
Inspect the condition of the optional undercarriage casters and the spring loaded height adjustment
assemblies and replace worn/damaged parts as necessary. Apply general purpose grease to
lubricate the spring loaded mechanisms as needed.
All cables and conduits should be inspected for breaks, abrasions and security.
PERIODIC INSPECTION & MAINTENANCE
NOTE: The following inspection & maintenance should be performed with greater
frequency if conditions and usage requires.
Periodically clean the machine with compressed air.
IMPORTANT: The gearbox oil must be changed after the first 300 hours of operation
(approximately 2 months of single shift usage) and then every 12,500 hours
thereafter.
The Gearbox is typically shipped from the factory with “Shell Tivela S 320” - a synthetic, ISO VG
320 oil. When replacing the gearbox oil, refer to the chart below for the best Viscosity Grade (VG)
oil to suit the operating environment of the machine. The gearbox requires 1 Gallon (US) [4 Litres]
of oil.
NOTE: Do not mix mineral oils with synthetic oils! If necessary to change from one type of
oil to the other, carefully wash the internal parts of the unit using suitable
detergents.
32
70ºF [0 - 20ºC] 70 - 104ºF [20 - 40ºC]
Mineral Oil
ISO VG
Synthetic Oil
ISO VG
Mineral Oil
ISO VG
Synthetic Oil
ISO VG
220 220 460 320
