GULLCO KBM-18 - Kbm -18 Motor Assembly Breakdown

49
KBM®-18 MOTOR ASSEMBLY BREAKDOWN
Item Part Number Description Qty
KBM-18-203-A
230/460V Motor Assembly (KBM-18-100-A, -B, -C & D)
Includes items 1, 151, 5001 & 5005
KBM-18-203-B
575V Motor Assembly (KBM-18-100-E)
Includes items 1, 151, 5001 & 5005
1 KBM-18-207 Cover 1
151 Not Sold Individually Pinion Gear 1
5001 KBM-18-5001 Oil Seal 1
5002 KBM-18-5002 Bolt 6 x 20 10
5005 KBM-18-5005 Gamma Seal 1
203 1
Note:
Provide all nameplate details from gear
box label when ordering spare parts.
