43
ITEM PART NUMBER DESCRIPTION QTY
1 KBM-18-067 MAIN ROLLER 1
2 KBM-18-05759 MAIN ROLLER BEARING 1
3 KBM-18-05230 80mm INTERNAL RETAINING CLIP 1
MAIN ROLLER ASSEMBLY BREAKDOWN
Part Number: KBM-18-026
