Table of Contents

Table of Contents3
Safety Instructions5
Kbm®-18 Plate Edge Bevelling Machine Details7
- Machine Specifications7
- Bevelling Capacity9
General Description10
Intended / Foreseen Usage10
Lifting (Hoisting)11
Installation12
- Electrical Connection12
- Mechanical Installation14
- Cutter Installation15
Operation16
- Bevel Settings16
- 22.5º Bevel Arrangement23
- 30º Bevel Arrangement23
- 37.5º Bevel Arrangement24
- 45º Bevel Arrangement24
- 55º Bevel Arrangement25
- Root Face Scale Examples25
- Preparation for Self Propelled Operation26
- Preparation for Bench Operation27
- Bevel Operation28
- Interrupted Material Feed29
- Bevelling Flame Cut Steel Plates30
- Bevelling of Tougher Materials30
Cutter31
- Cutter Life31
- Sharpening Instructions for Kbm®-18 Cutters32
- Cutter Details33
- Forces Acting on the Cutter34
- Cutter Breakage Caused by External Forces35
Inspection & Maintenance36
- Daily Inspections36
- Monthly Inspections37
- Periodic Inspection & Maintenance37
Storage38
Shipping38
Troubleshooting Guide39
Kbm®-18-100 General Assembly Breakdown42
Clamp Roller Assembly Breakdown44
Pivot Arm Assembly Breakdown45
Slide Base Assembly Breakdown46
Main Roller Assembly Breakdown47
Support Roller Assembly Breakdown48
Starter Assembly Breakdown49
Manual Starter Assembly Breakdown50
Kbm ® -18 Main Gearbox Breakdown51
Kbm ® -18 Gearbox Additional Gear Module Breakdown52
Kbm ® -18 Motor Assembly Breakdown53
Optional Hydraulic Undercarriage Assembly Breakdown54
Optional Undercarriage Assembly Breakdown56
Kbm®-18 Wiring Schematic57
