2017_E_TYPE-HL.doc Page 21 of 55 24-Oct-2017
immediately in writing to the delivering carrier.
Concealed damage must be reported to the local agent of the delivering carrier
immediately upon discovery and in any event within 48 hours after receipt.
Guspro must always be notified when lost, short-shipments, or damages occur so that a
record can be made. This will aid supply of replacement parts and preparation of repair or
replacement cost estimates.
Purchaser must file the final claim promptly with the carrier.
3.7 Storage
Refractory should be dried out and cured as soon as possible. If the Oven cannot be
placed in immediate service, it must be protected during storage from freezing and rain. The
internal refractory surfaces, including the stack interior, must be protected from excessive
moisture until cured.
3.8 Installation
3.8.1 Introduction
Each oven is shipped with burners, gas manifolds and all electrical manifolds completely
assembled. The refractory-lined stack is shipped separately.
Installation involves setting the oven in position on a level concrete pad or floor.
Note
: The pad on the floor should be as level as possible. If the area is not level, this will be
reflected in the stack vertical plane when installed.
Some large units are shipped with the oxidizer chamber separate from the oven. Oxidizer
chamber installation is a bolt on assembly. Assembly instructions are included.
3.8.2 Stack Installation
The recommended method of venting flue gases from combustion inside the Oven is
straight up the refractory lined stack to the outside atmosphere. Ovens are supplied with three
six-foot sections of insulated stacking.
The stack sections normally bolt together and are bolted in place on top of the unit. In
case this is not feasible, breech stacking and fittings are available for through the wall installation
or other special requirements.
