NOTICE
Both the main gas valve and the electric supply should be clearly marked or tagged.
INSTALLATION
This unit shall be installed in accordance with the National Fuel Gas Code ANSI Z223.1,
The National Gas Installation Code CAN/CGA B149.1 or the Propane Installation Code
CAN/CGA-B 149.2, as applicable.
If applicable, the vent line from the gas appliance pressure regulator shall be installed to
the outdoors in accordance with local codes or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1, Natural gas Installation Code, CAN/CGA-B149.1,
or the Propane Installation Code, CAN/CGA-B149.2, as applicable.
The unit and its individual shut off valves must be disconnected from the gas supply piping
system during any pressure testing of that system at test pressures in excess of 1/2 PSI (3.45
Kpa).
The unit when installed shall be electrically connected and grounded in accordance with
local codes, or in the absence of local codes, with the National Electrical Code,
ANSI/NFPA70, or the Canadian Electrical Code, CSAC22.2, as applicable.
AFTER INSTALLATION
After installation, be sure to maintain adequate combustion and ventilation air. Do not
allow materials or articles to be stacked or piled near or against the oven or burners so as
to block or inhibit air flow. In the case of a through the wall installation, do not allow snow
or ice to build up around the burner covers or the oven relief lid.
NOTICE
The oven manual should be retained for future use. A “C” sized electrical diagram is
contained in the manual. An electrical diagram is placed in the electrical panel.
• The Process Chamber referred to in this manual is also known as the Primary
Chamber.
• The Oxidizer Chamber referred to in this manual is also known as the Afterburner
or Secondary Chamber.
It is recommended that the operator reads Sections 4.2-4.4 prior to powering up the unit!!
