OMRON TEMPERATURE CONTROLLER SETTINGS - PROCESS
The procedure shown below describes the programmable controller settings
utilized during the assembling and testing of the Guspro heat cleaning ovens. A
Guspro technician should be contacted if there is any deviation from the following
procedure.
To run a set program:
1. Press the scroll key PRG is in the upper display.
2. Press the up and down arrow keys until the pattern required shows in the
lower right hand display.
3. Press the scroll key repeatedly until the display is back to indicating the
chamber temperature and set point (regular display).
4. Push and hold the RUN/RST button until the cycle starts.
PROCESS
Omron Temperature Controller - Factory Settings
Chamber
Temperature
Setting (
o
F)
Controller LED
(light)
Process Chamber Output
Controlled by
program cycle
OUT 1
Process Alarm 1 (OTS Mist)
50
o
F (deviation
above set point)
OUT 2
Process Chamber Program Cycle
Cycle Start
SUB1
Optional
SUB2
To Next Page
