The Getting started chapter introduces the
oscilloscope’s main features, appearance, and set
up procedure.
Main Features
Model name
Frequency bandwidth
Input channels
GDS-1072A-U
DC – 70MHz (–3dB)
2
GDS-1102A-U
DC – 100MHz (–3dB)
2
GDS-1152A-U
DC – 150MHz (–3dB)
2
Performance
 1 GS/s real-time sampling rate
 25GS/s equivalent-time sampling rate
 2M points record length
 Up to 10ns peak detection
 2mV~10V vertical scale
 1ns ~ 50s time scale
Features
 5.7 inch color TFT display
 Saving and recalling setups and waveforms
 27 automatic measurements
 Multi-language menu (12 languages)
 Math operation: Addition, Subtraction,
multiplication, FFT, FFT RMS
 Data logging
 Go-NoGo testing
 Edge, video, pulse width trigger
