GDS-1000A-U Series User Manual
74
Edit: Source
Procedure
1. Press the Utility key.
Utility
2. Press the More key.
More
3. Press the Data logging Menu
key.
Data logging
Menu
4. Press Source repeatedly to
select the source channel
(CH1 or CH2).
Source
CH1
Edit: Setup Parameters
Background
The logging function must set the type of data that
will be logged (waveform/image), the capture
interval time and the duration of the data logging.
Procedure
1. Press the Utility key.
Utility
2. Press the More key.
More
3. Press the Data logging Menu
key.
Data logging
Menu
4. Press the Setup key.
Setup
