Run Data logging
Background
Ensure the data source (page 74) and data logging
setup has been set (page 74).
Procedure
1. Insert a USB flash drive into
the USB front panel port.
2. Press the Utility key.
Utility
3. Press the More key.
More
4. Press the Data logging Menu
key.
Data logging
Menu
5. Press Data logging to turn
data logging On.
Data/image files start
logging to the USB flash
drive automatically. To stop
the Data logging, press the
Data logging key again.
On
Data logging
