GDS-1000A-U Series User Manual
58
Editing a
measurement
item
3. Press the corresponding
menu key (F1~F5) to select
the measurement slot to be
edited.
Voltage
Vpp
4. The editing menu appears
Change
measurement
item
5. Use the Variable knob to
select a different
measurement item.
VARIABLE
Change
measurement
source
6. Press Source 1 repeatedly to
change Source1 from CH1
to CH2 or MATH.
Source 1
CH1
Range
CH1, 2, Math
