GW Instek GDS-1102A-U - Page 94

GDS-1000A-U Series User Manual
94
2. Press F4 repeatedly to select
voltage or current probes.
Voltage
x1
3. Use the variable knob to
edit the voltage or current
attenuation.
VARIABLE
4. The voltage/current scale in the channel
indicator changes accordingly. There is no
change in the waveform shape.
Range
0.1X~2000X (1-2-5 steps)
Note: The attenuation factor adds no influence on
the real signal; it only changes the voltage/current
scale on the display.
