H3C SecPath F1020 User Manual

12
Distance between the front and rear rack
posts
Rear mounting bracket installation
method
door.
Figure2-4 Attaching the rear mounting brackets (with the wide flange inside the rack)
Figure2-5 Attaching the rear mounting brackets (with the wide flange outside the rack)
7. Mount the firewall in the rack. Use M6 screws to secure the mounting brackets to the front rack
posts and make sure the shoulder screws rest firmly on the upper edge of the rear mounting
brackets.

H3C SecPath F1020 Specifications

General

Brand	H3C
Model	SecPath F1020
Category	Firewall
Language	English
