7-56
Port specifications
Console port
Table7-18 Console port specifications
Connector RJ-45
Standard compliant RS-232
Baud rate 9600 bps (default) to 115200 bps
Cable type Common asynchronous serial port cable
Transmission distance ≤ 15 m (49.21 ft)
Services
• Connection to an ASCII terminal
• Connection to the serial port of a local PC running the terminal
emulation program
• CLI
Micro USB console port
Table7-19 Micro USB console port specifications
Connector Micro USB
Standard compliant Micro USB
Baud rate 9600 bps (default) to 115200 bps
Cable type USB console cable
Transmission distance ≤ 10 m (32.81 ft)
Services
• Connection to an ASCII terminal
• Connection to the serial port of a local PC running the terminal
emulation program
• CLI
GE copper port
Table7-20 GE copper port specifications
Connector RJ-45
Standard compliance 802.3, 802.3u, and 802.3ab
Interface type MDI/MDI-X autosensing
Cable type Category 5 or higher twisted pair cable
Transmission distance 100 m (328.08 ft)
Interface speed and duplex mode 10 Mbps, half/full-duplex
