H3C SecPath F1020

7-51
Figure7-15 PSR250-12A1 power module
(1) Latch
(2) Status LED
(3) Handle
(4) Power receptacle
DC power modules
PSR150-D1
The PSR150-D1 power module with a product code of PSR150-D1-B provides a maximum output
power of 150 W.
Figure7-16 PSR150-D1 power module
(1) Handle
(2) Power receptacle
PSR450-12D
The PSR450-12D power module with a product code of PSR450-12D provides a maximum output
power of 450 W.
1
2
4
3
1 2
