Haefely Technology AXOS5 - 3 Technical Data; General; Surge; Burst

4 AXOS
5
Compact immunity test System
3 Technical data
3.1 General
General Data
Control Power 85V - 264V
50/60 Hz
Dimensions
(W x H x D)
19" / 4U
(45 x 18 x 49 cm)
User Test Storage Unlimited Weight 30kg
Remote Interface Ethernet
RJ45
USB for USB memory stick
Display 7" / 800x480 / 24bit
with touch-screen
AUX Interface D-sub 37p for external CDN,
external transformer etc.
External Trigger Input 5V TTL Synch Input BNC, 10V – 264V AC
Trigger Output 5V TTL External Start / Stop
Input
5V TTL, starts / stops
predefined test sequence
EUT failed Input 5V TTL Analog Output 0 – 10V, for use with external
options
Warning Lamp Output 2 x 24V / 1A DC Safety Circuit stops the test when unlocked
Table 3-1: General data
3.2 Surge
IEC / EN 61000-4-5 Edition 2 Surge Combination Wave
Output Voltage 0.2 – 5.0kV ±10% Output Current 0.1 – 2.5kA ±10%
Voltage Rise Time 1.2us ±30% Current Rise Time 8us ±20%
Voltage Duration 50us ±20% Current Duration 20us ±20%
Polarity pos / neg / alternate
Output Impedance 2 Ohms
Phase Sync 0 – 359° with 1° steps
or asynchronous mode
Integrated Single
Phase CDN
264V AC / 16A
220V DC / 10A
Counter preselect
Counter
1 – 1000
infinite
100000
Impulse Trigger automatic 2s – 100 minutes
manual
external trigger input
Peak Voltage
Monitor
BNC output: 1000:1
Display: 3 Digits
Peak Current
Monitor
BNC output: 1kA/V
Display: 3 Digits
Table 3-2: Surge data
3.3 Burst
IEC / EN 61000-4-4 Edition 2 EFT / Burst
Output Voltage 0.2 – 5.0kV ±10% at
coaxial output
Spike Frequency 1Hz – 1MHz
Polarity pos / neg / alternate Burst Duration 10us – 1s
Output Impedance 50 Ohms Burst Period 1ms – 10s
Rise Time 5ns ±30% Test Time 1s– 1000 minutes
Impulse Duration 50ns ±30% at 50
Ohm
50ns –15 +100ns
at 1000 Ohm
Trigger automatic
manual
external trigger input
Burst Mode normal
continuous
real
random
Integrated Single
Phase Coupling /
Decoupling Network
264V AC / 16A
220V DC / 10A
Table 3-3: Burst data
