Compact immunity test System 5
3.4 Voltage dips
IEC / EN 61000-4-11 Edition 2 and IEC / EN 61000-4-29 Dips & Interrupts
Max. Voltage 264V AC/DC Interrupt Time 0.5 period – 800 periods
100us – 1000 minutes
Max. Current 16A AC/DC continuous
20A for 5s
40A for 3s
500A inrush Current
Interval Time 1 period – 800 periods
synch
100us – 1000 minutes
async
Trigger automatic
manual
external trigger input
Test Time 1s – 1000 minutes
Infinite
Interrupt
Dip Level
0%
0% – 99% with
external voltage
source
Phase Sync 0 – 359° 16 / 40 / 50 / 60 Hz
asynchronous Mode
RMS Voltage Monitor BNC Output: 100:1
Display: 4 Digits
RMS Current
Monitor
BNC Output: 10A/V
Display: 4 Digits
Table 3-4: Voltage dips and interrupts data
3.5 Integrated single-phase CDN
AXOS
5
provides an integrated single-phase coupling / decoupling network for Burst and Surge tests.
It is protected against over-current by an integrated protection circuit. Current limit can be selected between 1A to 16A
in the PROPERTIES menu.
The integrated CDN may be used with AC or with DC power lines.
The input of the integrated CDN (i.e. EUT Supply Input) must be connected to power lines which are protected by a
line safety switch equal or less 16A rated current and characteristic B or C.
