8300 Low Energy Auto-Operator
Installation Instructions
I-EA00257 / 26790910
Rev 2, Rev Date: 1/30/19
Always visit www.hagerco.com for the latest Installation Instructions
HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995
J4, J5, and J6 Terminal Inputs
Terminal Function Description
1
Electric Lock Relay Common
2
Electric Lock Relay
N.O. Dry contact – Contact closes upon activation. May be used for fail-secure locks by routing 1
leg of power though the relay. Relay is triggered by activation inputs 10, 11, or 16. Relay
remains energized until door is fully closed again.
3
Electric Lock Relay
N.C. Dry Contact - Contact opens upon activation. May be used for fail-safe locks by routing 1
leg of power though the relay. Relay is triggered by activation inputs 10, 11, or 16. Relay
remains energized until door is fully closed again.
4
Door Status -
Closed
N.O. Contact is closed when door is closed. The contact opens as soon as the door opens.
5
Door Status - Com Common contact for door status
6
Door Status -
Open
N.C. – Contact is closed when door is open. The contact opens as soon as the door starts to
close. This input can be used for motor connection at lockout relay when power is looped
through, thus switching power on when door is open.
7
GND Common Ground
8
GND Common Ground
9
(+) 24VDC 1 A. Max Current
10 Internal Activation
Requires N.O. Contact between input 10 & GND. Remains capable to activate when dip switch 3
is ON AND On-Off switch is OFF.
11
External Activation Requires N.O. Contact between input 11 & GND.
12
Emergency
Closing
Requires N.C. contact between 12 & GND. Upon open contact, door closes and overrides all
other inputs. Remains jumpered if input is not used.
13
Secondary
Activation
Requires N.C. contact between 13 & GND. Disabled in full closed position.
14
"Stall" Safety
Requires N.C. contact between 14 & GND. Upon open contact, (Dip 6 OFF) during opening, door
stops, then resumes at reduced speed when input is released.
15
KEY KEY INPUT
16
Alarm Input
N.O. contact, when closed causes door closing. All inputs inhibited during closed contact (not
available on all software versions)
17
Overhead
Presence Sensor
Input
Requires N.O. contact between 14 & +24 VDC (input 9). When input is closed it causes an open
door to stay open and a closed door to stay closed. Works in conjunction with dip switch #6.
18
GND Common Ground
19
GND Common Ground
20
Aux Relay Auxiliary Relay NOTE: Relay is triggered by input 14
21
Aux Relay Auxiliary Relay N.O.
22
Aux Relay Auxiliary Relay N.C.
23
Alarm Output -
Com
Common
24
Alarm Output N.O. output is closed upon closed contact from fire alarm. LED 2 also illuminates.
25
(+) 24VDC 1 A. Max Current
26
GND Common Ground
Terminal Strip J5
Terminal Strip J4
Terminal Strip J6
Page 16 of 18
