hager 8300 Series User Manual

8300 Low Energy Auto-Operator
Installation Instructions
I-EA00257 / 26790910
Rev 2, Rev Date: 1/30/19
Always visit www.hagerco.com for the latest Installation Instructions
HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995
The Hager 8300 series low energy auto-operators offer state-of-the-art micro-processed controllers with
electro-mechanical drive. The unique slim-line design offers non-handed operation, full mechanical stops,
and numerous interface options for sensors, push-plates, fire alarms and electric locks. The unit includes
onboard diagnostics to simplify troubleshooting when needed.
PRODUCT DESCRIPTION & SPECIFICATIONS
Power Supply
Power Consumption
Current Consumption
Motor
Header Dimensions
Fused Protection
Weight
Ambient Operating Temperature
Ingress Protection
Push Arm Pull Arm
36" Door 438 lbs 342 lbs
42" Door 328 lbs 256 lbs
44" Door 299 lbs 234 lbs
48" Door 254 lbs 198 lbs
24 VDC Accessories Power Supply
24 VDC Electric Lock Power Supply
Adjustable Speeds & Timers
Standard Selector Switch Functions
Standard Control Outputs
Standard Control Inputs
Maximum Door Weight
115 VAC (+6%, -10%) 60Hz
100W
1A
24 VDC Permanent Magnet With Belt Driven Encoder
20 3/4” x 4 1/8” x 4 3/4” (l x w x d)
3.5A Fuse (F1 located on I/O Board)
22 lbs Per Operator Assembly
-4 to 131º F
IP23
24 VDC / I A. Max
24 VDC / I A. Max
Automatic
Hold Open
Manual (Off)
Malfunction Alarm
Electric Lock Relay
24VDC Accessories Power Supply
Door Status
Interior Activation
Exterior Activation
Emergency Shutdown
Alarm Output
Safety Device Input
Secondary Activation
Opening Speed
Closing Speed
Hold Open Time
Closing Speed with power off
