High-output, temperature controlled
soldering station
Instruction Manual
●
Thank you for purchasing the FP-102 soldering station. This
high-output, temperature controlled soldering station uses a
composite tip, incorporating heater and sensor functions into
one element. Several process control features unique to the
FP-102 make it applicable to a broad range of soldering ap
-
plications.
Please read this manual before operating the FP-102 . Keep
this manual readily accessible for reference.
●
TABLE OF CONTENTS
1. PACKING LIST ............................................................... 1
2. SPECIFICATIONS ..........................................................
1
3. WARNINGS, CAUTIONS, NOTES AND EXAMPLES ....
2
4. PART NAMES .................................................................
3
5. INITIAL SETUP ...............................................................
3
6. OPERATION ...................................................................
5
7. PARAMETER SETTINGS ...............................................
6
8. MAINTENANCE ..............................................................
7
9. ERROR MESSAGES ......................................................
9
10. TROUBLE SHOOTING GUIDE ....................................
10
11. PARTS LIST ................................................................. 11
12. TIP STYLES .................................................................
13
13. WIRING DIAGRAM .......................................................
15
