Heat resistant pad
Iron holder
FP-102 Soldering station
Control card
Card chain
Tip tray
Tip (not included)
FM-2021 Connector assembly
Sleeve assembly*
7
.5
6.5
8.0
7
.0
M
O
D
E
L
F
P
-
1
0
2
*Yellow, orange or blue sleeve
assembly is included.
1. PACKING LIST
FP-102 soldering station .................................
1
FM-2021 connector assembly ......................... 1
Sleeve assembly ............................................ 1
Control card, with chain ................................... 1
Heat resistant pad ...........................................
1
Tip tray ............................................................. 1
Iron holder ....................................................... 1
Cleaning wire ................................................... 1
Instruction manual ........................................... 1
2. SPECIFICATIONS
FP-102 Soldering Station
Power Consumption
Temperature Range
Temperature Stability
75 W
The four segment lights on the front
panel indicate the heat range selected
for the FP-102 (6.5 = ~650°F. [343°C];
7.0 = ~700°F. [371°C]; 7.5 = ~750°F.
[399°C]; 8.0 = ~800°F. [427°C]).
±9°F (±5°C) at idle temperature
Power Consumption
Tip to Ground Resistance
Tip to Ground Potential
Total Length (w/o cord)
Weight (w/o cord)
Cor
d
70 W (24 V
)
< 2
< 2 mV
188 mm (7.4 in.) with 2.4D tip
30 g (0.067 lb./1.07 oz.) with 2.4D tip
1.2 m (4 ft)
Soldering Iron
Output
Dimensions(W
H D)
Weight (w/o cord
)
24 V
120 93 140 mm (4.7 3.7 5.5 in.)
1,400 g (3.1 lb.)
Station
NOTE:
This product is protected against electrostatic discharge.
Specifications and design are subject to change without notice.
Please check to make sure that all items listed below are includ-
ed in the FP-102 package.
