HAKO 980 E/EH - Brake and Hydraulic System

2.8 Brake
The Hako-Jonas 980 E/EH is equip-
ped with a service brake.
This brake has been constructed as
shoe brake and equally serves as par-
king brake.
It is located in the rear wheels and is
actuated via cables.
A special adjustment screw is situated
at the right-hand rear wheel.
Works at the braking
system have to be executed
by qualified persons in a
qualified workshop only.
2.9 Travel Drive Assembly
The Hako-Jonas 980 E and EH is
equipped with an electric drive assem-
bly with continuous regulation.
2.10 Hydraulic System
The hydraulic system includes a com-
pact unit (hydraulic pump with hydrau-
lic tank) as well as hydraulic hoses
and a hydraulic cylinder.
Hydraulic fluid: Mobiloil DTE 15 M
The hydraulic system has been filled
with fluid in the factory.
Filling of hydraulic fluid tank: 0.76 litre
18
