7.12.2 Lifted-Up Disposal
Fuses/Relays
20 K6 Lifted-up disposal
21 K7 Lifted-up disposal
22 K8 Lifted-up disposal
23 K9 Lifted-up disposal
24 K10 Relay, lift dirt hopper
25 K11 Relay, lower dirt
hopper
26 F 13 Hydraulic unit (30A)
Lifted-up disposal fuses/relays
54
Maintenance/Service
Fig.27
7.12.2 Lifted-Up Disposal
Fuses/Relays
20 K6 Lifted-up disposal
21 K7 Lifted-up disposal
22 K8 Lifted-up disposal
23 K9 Lifted-up disposal
24 K10 Relay, lift dirt hopper
25 K11 Relay, lower dirt
hopper
26 F 13 Hydraulic unit (30A)
Lifted-up disposal fuses/relays
54
Maintenance/Service
Fig.27
