HAKO 980 E/EH - Primary Operating Controls

27
1 Actuator for folding apron
to open and close the folding apron
for collecting coarse dirt.
2 Service brake/parking brake lock
to lock the service brake/parking
brake. If locked, the service brake
works as parking brake. Release
the lock by depressing the service
brake pedal (3).
3 Service brake/parking brake
pedal
to actuate the service brake at the
rear wheels. Before leaving the
machine unattended, engage the
service brake and lock.
4 Drive pedal, reverse
to change direction to reverse ride
and with continuous regulation of
riding speed at the same time. If
the driver lets the pedal go it re-
turns to initial position and the ma-
chine slows down to standstill.
5 Drive pedal, forward
to change direction to forward ride
and with continuous regulation of
riding speed at the same time. If
the driver lets the pedal go it re-
turns to initial position and the ma-
chine slows down to standstill.
6 Control panel
Refer to chapter "Control panel"
7 Seat adjustment
to adjust the seat position to dri-
vers of different height.
Adjust the seat so as to allow the
driver being comfortably seated
and attaining all elements required
for operation.
- Adjust seat lengthwise: push lever
slightly to the right and displace seat
forwards or backwards to the required
position. Then let the lever catch
again.
Operation
