18
Operation
2.2.5 Installing the driving/block
battery
1. Switch off the vehicle with the key
switch and secure it by applying the
parking brake.
2. Open the seat console (Fig. 6/1).
3. Position the batteries in the battery
tray in accordance with the figure.
Replacing/Installing is only
possible with the aid of appro-
priate lifting gear. Please read
the information provided in the
operating manual of the bat-
tery manufacturer. For reasons
of safety, we strongly recom-
mend having this work com-
pleted at an authorized Hako
service center.
4. Connect the battery poles in accor-
dance with the connection diagram
(Fig. 6/2).
5. Pay attention they are firmly fixed
and grease the poles.
6. Check the battery plug (Fig. 6/3),
refer to Section 2.2.6.
Fig.6
