HAKO Hakomatic B115R - Cleaning and Component Servicing Procedures

57
Maintenance and Service
5.5 Waste water and clean water
tank
1 Tank lid
2 Maintenance opening, clean water
tank
3 Filling neck, clean water tank
4 Draining hose, clean water tank
5 Draining hose, waste water tank
6 Filter sieve
7 Float switch, waste water tank
8 Cleaning opening, sieve
9 Fill level indicator, clean water tank
10 Clean water sieve with holding band
for the filling neck (option)
11 Clean water filter
12 Clean water tank
13 Waste water tank
Fig.24
1
2
4
5
6
7
8
9
2
12
10
11
13
2
3
