26
Operation
2.3.6 Switching the vehicle on
For safety reasons, the driver's
seat is equipped with a seat
contact switch. The vehicle can
only be started when the oper-
ator is sitting on the driver's
seat.
1. Pull the power plug (Fig. 13/1) from
the socket and place it in the holding
recess.
2. All control levers must be in their
neutral position.
3. Switch on the vehicle with the key
switch (Fig. 13/3) and set the re-
quired direction using the driving di-
rection selection switch (Fig. 13/5).
The operating hour counter
(Fig. 13/4) displays the software ver-
sion, the last service code (if applica-
ble) and operating hours in
succession. Service code table, refer
to Section 2.4.
Fig.13
