Use
Charging state indicator Fig. 3-10
The charging state of the battery is indicated on the display panel during
operation. The number of bars shown indicates the charging state:
• Five green bars visible: Battery is 100 % charged.
• Four green bars visible: Battery is approx. 80 % charged.
• Three green bars visible: Battery is approx. 60 % charged.
• Two green bars visible: Battery is approx. 40 % charged.
• One green bar visible: Battery is approx. 20 % charged.
• One yellow bar visible: Machine can only be operated for
approx. 2 minutes.
Charge the battery immediately!
• One red bar visible: Battery is empty. All functions are switched off.
