Maintenance and servicing
5.5 Cleaning/replacing the cleaning tools
Clean the cleaning tools daily or replace them when worn. The cleaning tools
must be changed when the red wear bristle has been reached Fig. 15-2.
1. Turn the machine off and lock the operating bar.
2. Remove the tanks, see section 5.4.1.
3. Remove the battery, see section 5.7.2 and place the machine on the
floor Fig. 15-1.
4. First pull off the outer and then the inner cleaning tool with both
hands Fig. 15-4 and clean the tools, or replace them when worn.
5. After cleaning/replacing the tools, first press the inner and then the outer
cleaning tool firmly into the holder with both hands Fig. 15-3.
