© HAMM AG 2009 75
MAINTENANCE
• Open the hollow screw D of the purge line
at the engine block by three turns (do not
remove!). Hold up the screw-in fitting E at
the hexagon!
• Fill new, properly mixed refrigerant into the
filling spout A of the compensation tank,
until refrigerant spills from the hollow
screw.
• Tighten the hollow screw.
• Fill up refrigerant up to the max. mark of
the compensation tank B.
• Close the filling spout.
• Start the engine and bring it to operating
temperature (thermostat opens).
• Shut down the engine.
• Check refrigerant level when the motor is
cold, fill up as necessary.
• Correct refrigerant level: Between the Min.
and Max. mark at the compensation tank
B.
15013-10
DE
Only lubricants with this identification are
admissible, see lubricant indications 3.2.
