GENERAL
1.1.3 Special identifications in the text
The following symbols or notes are used for
the identification of text which do not apply to
all machine variants:
/i
/i
/i
Positions in figures
The positions in the figures are represented
with letters and numbers. The positions identi-
fied with letters in alphabetical order are only
explained in the corresponding text segment,
beginning new for each single figure. The posi-
tions identified with numbers correspond to the
numbering of the plates for operating ele-
ments, control devices and switches. They are
identical to the numbers of the individual oper-
ating and control elements. In the describing
text, these position numbers are in brackets.
Among other things, this ensures that impor-
tant and additional information can be found
immediately and without difficulties in the de-
scriptions of the elements.
All rights reserved
No part of this publication my be reproduced,
processed, copied and/or published in any way
(imprint, photocopy, microfiche or any other
procedures) without the written consent of
HAMM. This also applies to the corresponding
drawings and schemes.
HAMM reserves the right to change individual
parts at any time without previously informing
the customer. The contents of this publication
can also be changed without prior announce-
ment.
This publication applies to the standard design
of the previously listed machine types. There-
fore it is possible that these instructions include
descriptions of components not installed in
your machine. HAMM does not accept liability
for possible damages resulting from the appli-
cation of this publication on machines deviat-
ing from the standard design.
Please contact to the customer service of your
supplier for all information about adjustment,
maintenance or repair work not included in this
publication.
Only for machines with CE equipment
Only for machines without CE equipment
Option Special equipment
