Hamm HD 8 VV - 4 Tables; Diagnostic Code

© HAMM AG 2009 77
TABLES
4TABLES
4.1 DIAGNOSTIC CODE
/i
00 no malfunction
01 Reversing lights (option)
Short-circuit
03 Left working lamp (option)
Short-circuit
05 Right working lamp (option)
Short-circuit
07 Drum illumination (option)
Short-circuit
11 Left headlight (option)
Short-circuit
13 Right headlight (option)
Short-circuit
18 Rear vibration solenoid or amplitude solenoid
Short-circuit, line rupture
19 Rear vibration solenoid
Short-circuit, line rupture
21 EMERGENCY STOP solenoid (NOT-STOP) or
front vibration solenoid
Short-circuit, line rupture
22 EMERGENCY STOP solenoid (NOT-STOP)
Short-circuit, line rupture
23 Front vibration solenoid
Short-circuit, line rupture
26 Rotating beacon (option)
Short-circuit
27 Water irrigation pump
Line rupture
28 Water irrigation pump
Short-circuit
29 Alternator
Short-circuit, line rupture
30 Parking light
Short-circuit
