Hammond XK-1 User Manual

*#1 :-Owner’s Manual
Appendix100
Leslie Parameters
System Parameters
Category
DATA
Parameter
LSB
(62)
MSB
(63)
LSB
(62)
MSB
(63)
MSB
(06)
Default
Name
(10 Characters)
Slow Speed Horn
06 00 7F 00
00 - 63(0, 24 - 318rpm) 05 (36rpm)
Slow Speed Bass
06 01 7F 01
00 - 63(0, 24 - 318rpm) 05 (36rpm)
Fast Speed Horn
06 02 7F 02
00 - 1A(0, 375 - 453rpm) 07 (393rpm)
Fast Speed Bass
06 03 7F 03
00 - 1A(0, 375 - 453rpm) 07 (393rpm)
Rise Time Horn
06 04 7F 04
00 - 18(0.2 - 5.0s) 0A (2.2s)
Rise Time Bass
06 05 7F 05
00 - 18(0.5 - 12.5s) 0D (7.0s)
Fall Time Horn
06 06 7F 06
00 - 18(0.2 - 5.0s) 04 (1.0s)
Fall Time Bass
06 07 7F 07
00 - 18(0.5 - 12.5s) 09 (5.0s)
Brake Time Horn
06 08 7F 08
00 - 18(0.2 - 5.0s) 05 (1.2s)
Brake Time Bass
06 09 7F 09
00 - 18(0.5 - 12.5s) 13 (10s)
Volume Horn
06 0A -- --
00 - 0C(-12 - 0dB) 0C (0dB)
Volume Bass
06 0B -- --
00 - 0C(-12 - 0dB) 0C (0dB)
Mic. Angle
06 0C 7F 0A
00 - 06(0 - 180deg) 04 (120deg)
Mic. Distance
06 0D 7F 0B
00 - 08(0.3 - 2.7m) 02 (0.9m)
Horn Character
06 0E -- --
00 - 02(Flat, Mid, Deep) 00 (Flat)
NRPN on XK
Cabinet
#1 - 8
Leslie Parameters
NRPN on 21
Category
Parameter
Data Range
Default
MIDI
MIDI In Port Lower/Pedal , In1/In2 In1/In2
Local Off / On On
TRx. NRPN Off / On On
Tx. Leslie Param. XK / 21 XK
TRx. Prog. Change Off / On On
TRx. Drawbar Regi. Off / On On
TRx. Wheel Control Off / On On
Rx. Dump Off / On On
TRx. Channel Upper 1 - 16, Off 1
TRx. Channel Lower 1 - 16, Off 2
TRx. Channel Pedal 1 - 16, Off 3
Display
To Shortcut 0, 1, 2s, No 1s
Time Out 4, 8, 16, No No
Key
Depth Normal / Deep Normal
Drawbars
Drawbar Select Upper, Pedal, Lower Upper
Expression
Gain 70 - 130% 110%
S
y
stem Parameters
