Hammond XK-1 User Manual

*#1 :-Owner’s Manual
18
CONNECTING THE MIDI KEYBOARD
You can upgrade this keyboard to an organ by connecting an external MIDI Key-
board and pedal keyboard.
1. Hook-up external MIDI keyboard and pedal keyboard per the figure above.
2. Use the MIDI Template “Seq. Record” of this keyboard. (P. 84)
3. To use Expression Pedal, set the parameter “EXPRESSION SOURCE” for the model of
expression pedal that you have connected. (P. 59)
The MIDI Keyboard connected to the PEDAL Terminal functions as the PEDAL
(part), and the one connected to the LOWER Terminal as the LOWER (part).
Please also read the User's Guide of the connected MIDI Keybaord.
MIDI Keyboard
MIDI Pedal
Keyboard
Expression Pedal
V-20R
