*#1 :-Owner’s Manual
Appendix96
System Exclusive Message
Memory Dump Mode Setting Exclusive Message
1.Each Packet Full Parameters Reset
F0
System Exclusive
F0
System Exclusive
55 SUZUKI ID 55 SUZUKI ID
00
Device ID
10
Device ID for DT1
10
Model ID MSB
42
Model ID for DT1
15 Model ID LSB 12 Command: DT1
11
Command: Data Packet
40
Address MSB
[TYPE]
Data Type
00
Address
02h= Setup Dump 7F Address LSB
[PNH]
Packet Number MSB
7F
Reset
[PNL] Packet Number LSB 42 Check Sum
[DATA]
64 Bytes Data
F7
End of Exclusive
128 Bytes nibblized ASCII When this device receives this message, it is reset to
ex: 7Eh = 37h, 45h the initial status of Full Parameter, and gets ready
[CHD] Check Digit for receiving
Lower 7 bits of XOR [DATA] the music data for the this device correctly.
F7
End of Exclusive It takes about 50ms to process this message.
Take an interval before the next message.
2.Acknowledge
F0
System Exclusive
55 SUZUKI ID
00
Device ID
10
Model ID MSB
15 Model ID LSB
14
Command: Acknowledge
[AK] Result: 00h=OK
05h=Check Digit Error
06h=Receive Protected
[PNH] Packet Number MSB
[PNL]
Packet Number LSB
F7 End of Exclusive
3.Hand shake communication
Master Slave
Packet 0 ->
<- Acknowledge 0
Packet 1 ->
<- Acknowledge 1
.....
This device will wait for 20ms if no acknowledges
is received and transmit the next data of the
packet number. (One Way Transfer)
NRPN Switch
F0
System Exclusive
55 SUZUKI ID
00 Device ID
10
Model ID MSB
15 Model ID LSB
02
Command: NRPN Sw.
[DATA]
00h=Off, 7Fh=On
F7
End Of Exclusive
When this device receives this message, switch
Tx&Rx NRPN in Control channel.
