HAMWORTHY HEATING LTD
6
FLEET V series 500001213/G
Figure 3.2.2 – F125/150V - water pipe work kit (3 high boiler installation shown)
750
620
750
360
120
FLOW
DN125
GAS
R2”
RETURN
DN125
130
750120
396
656
786
1/2” BSP Socket
for pressure gauge
