Hamworthy F85V - Figure 3.1.2 Table Dimensions and Clearances

HAMWORTHY HEATING LTD
5
FLEET V series 500001213/G
Figure 3.2.1 – F40/F100V - water pipe work kit (2 high boiler installation shown)
504
350
100
110
GAS
R 1 ”
1/2
FLOW
DN80
RETURN
DN80
600
750750
120
Figure 3.1.2 - Table Dimensions and clearances
BOILER MODEL
Dimension
F40V –F100V
A
580
580 680 680
B
320 320 320 350
C*
150 150 150 200
F125V—F150V
Two high
Three high
Two high
Three high
C - a 150Ø flue manifold is provided to connect the modules
C* - for models F125V-375 & F150-450, the flue termination is 200Ø
1/2” BSP Socket
for pressure gauge
386
540
636
